EJOT® self-drilling screw JT6-6-5.5

Hauptproduktbild

Specification

  • Applications

    • Fastening profiled steel sheets to 1.5 – 5 mm steel substructure
    • Fastening profiled aluminium sheets and sandwich panels to 1.5-5 mm steel substructure

  • Properties

    • A4 stainless steel with hardened drill point
    • Stainless steel sealing washer
    • Pre-assembled sealing washer

  • Technical specifications

    • Diameter: 5.5 mm
    • Drilling capacity tI + tII: 1.0 + 5.0 mm / 2.0 + 4.0 mm
    • Drive: Hexagon A/F8
    • Installation rotation speed: max. 1300 rpm

Filter

Selected filters

    Orderidentifier Article Number ø mm Ø Sealing Washer mm Length mm Clamp thickness mm Unit
    JT6-6-5,5x25 7380306331 5.5 0 - none 25.0 1.2 - 10.0 500

    Specifications

    ø
    5.5
    Ø Sealing Washer mm
    0 - none
    Length
    25.0
    Clamp thickness
    1.2 - 10.0
    Fastener material
    Orderidentifier
    JT6-6-5,5x25
    Unit
    500
    JT6-6-5,5x25 E16 3572281991 5.5 16 25.0 7.0 - 0.0 500

    Specifications

    ø
    5.5
    Ø Sealing Washer mm
    16
    Length
    25.0
    Clamp thickness
    7.0 - 0.0
    Fastener material
    Stainless Steel
    Orderidentifier
    JT6-6-5,5x25 E16
    Unit
    500
    3572282991 5.5 19 25.0 1.2 - 8.0 500

    Specifications

    ø
    5.5
    Ø Sealing Washer mm
    19
    Length
    25.0
    Clamp thickness
    1.2 - 8.0
    Fastener material
    Orderidentifier
    Unit
    500
    JT6-6-5,5x25-E22 3572283991 5.5 22 25.0 0.0 - 7.0 500

    Specifications

    ø
    5.5
    Ø Sealing Washer mm
    22
    Length
    25.0
    Clamp thickness
    0.0 - 7.0
    Fastener material
    Orderidentifier
    JT6-6-5,5x25-E22
    Unit
    500
    7380724331 5.5 0 - none 35.0 1.2 - 19.0 500

    Specifications

    ø
    5.5
    Ø Sealing Washer mm
    0 - none
    Length
    35.0
    Clamp thickness
    1.2 - 19.0
    Fastener material
    Orderidentifier
    Unit
    500
    3572581991 5.5 16 35.0 1.2 - 17.0 500

    Specifications

    ø
    5.5
    Ø Sealing Washer mm
    16
    Length
    35.0
    Clamp thickness
    1.2 - 17.0
    Fastener material
    Orderidentifier
    Unit
    500
    JT6-6-5,5x50 E16 3572481991 5.5 500

    Specifications

    ø
    5.5
    Ø Sealing Washer mm
    Length
    Clamp thickness
    Fastener material
    Orderidentifier
    JT6-6-5,5x50 E16
    Unit
    500
    JT6-6-5,5x50 E19 3572482991 5.5 500

    Specifications

    ø
    5.5
    Ø Sealing Washer mm
    Length
    Clamp thickness
    Fastener material
    Orderidentifier
    JT6-6-5,5x50 E19
    Unit
    500
    JT6-6-5,5x50 E22 3572483991 5.5 500

    Specifications

    ø
    5.5
    Ø Sealing Washer mm
    Length
    Clamp thickness
    Fastener material
    Orderidentifier
    JT6-6-5,5x50 E22
    Unit
    500
    JT6-6-5,5x35 E19 3572582991 5.5 500

    Specifications

    ø
    5.5
    Ø Sealing Washer mm
    Length
    Clamp thickness
    Fastener material
    Orderidentifier
    JT6-6-5,5x35 E19
    Unit
    500
