EJOTĀ® Iso-Corner

Specification

  • Applications

    Fastening components and brackets to thin-walled metal profiles for photovoltaic installations:

    • Fastening trapezoidal sheet flashings, clips for fixing standing seam systems or pre-punched retainers to thin-walled steel substructures (e.g. profiled sheets)
    • Fixing wind deflector sheets to profiled elements
  • Properties

    • A2 stainless steel with hardened steel drill point
    • Stainless steel sealing washer
    • Pre-assembled sealing washer
    • Non-skid application
    • Fastening with reduced swarf
    • Excellent gripping properties
  • Technical specifications

    • Diameter: 6.0 mm
    • Drilling capacity tI + tII: 0.88 + 0.88 mm
    • Drive: Hexagon A/F8
    • Installation rotation speed: max. 1800 rpm

ETICS products are only available from system suppliers

Filter

Selected filters

    Orderidentifier Article Number Unit
    Iso-Corner 200 8778200070 1

    Specifications

    Orderidentifier
    Iso-Corner 200
    Unit
    1
    Iso-Corner 300 8778300070 1

    Specifications

    Orderidentifier
    Iso-Corner 300
    Unit
    1
