KERI

Applications

• For subsequent securing of rain screen
• horizontal and vertical anchor arrangement

Order information: Further lengths upon request

Properties

• A4 stainless steel
• Instant loading capacity

Technical specifications

TECHNICAL DATA
permitted transverse loadF_Q: 8,5 kN
permitted side load M_Z: 1070 Nm

Note: For more information please see the product guide „external wall panel protection anchors“. Our service team will assist at any time, phone +49 351 4 53 67-0.

External wall panel protection anchors by EJOT®
The so-called 3 layer board consists of a bearing shell and external wall panel with insulation in between.

Tests have shown that subsequent renovations becomes necessary due to faulty support anchor materials or an insufficient number of anchors.

During renovation additional loads are often applied (insulation, facade). We recommend the EJOT® external wall panel protection anchors WSS and KERI as especially economic solution for the subsequent fixing of the wall panel to the existing substructure.
